Features:
- Supports 32-bit 33/66MHz PCI Bus
- Supports 10/100/1000Mbps Nway Auto-Negotiation
- Supports 10/100Mbps full and half duplex, 1000Mbps full duplex
- Supports Full Duplex Flow Control (IEEE 802.3x)
- Supports IEEE 802.1P, IEEE 802.1Q VLAN tag
- Supports Jumbo Frame
- Supports Auto-MDI/MDIX
- Provides Bootrom slot, supporting remote boot
- Supports ACPI, PCI power management
- Contain two large independent receive and transmit FIFOs
- One STP/UTP connector
- Provides LEDs to indicate network Link/Activity/Speed/Duplex
- Plug and Play

Specification:
Standards and Protocols
IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.1q, 802.1p
CSMA/CD, TCP/IP, PCI Revision 2.1/2.2

Interface
32-bit PCI

Transmission Rate
10/100Mbps for Half-Duplex mode
20/200/2000Mbps for Full-Duplex mode

Flow Control
IEEE 802.3x Flow Control (Full-Duplex)

Jumbo Frame
7680Bytes

Port
10/100/1000Mbps RJ45

Slot
1 BOOTROM slot

Network Media
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
1000Base-T: UTP category 5, 5e cable (maximum 100m)

LED Indicator
1000M Link/Act, 100M Link/Act, 10 Link/Act, Duplex

Safety & Emission
FCC, CE

Environment
Operating Temperature: 0C~40C
Storage Temperature: -40C~70C
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing

Operating System
Windows 95/98/ME/NT4.0/2000/2003/XP/Vista, Netware, Linux
