Features
- The product is equipped with Zalmans patented VFP (Variable Fin Profile) technology. Fan installed inside the heatsink maximizes the cooling efficiency and the products maximized dissipation surface area provides excellent performance.
- Use of four high performance heatpipes maximizes heat transfer.
- Pure copper thin fins (0.3mm) for excellent cooling performance.
- Cools not only the VGA chipset and VGA RAM, but all other VGA components as well.
- 80mm Slim LED Fan for excellent performance and great aesthetics.
- Newly improved installation structure provides easy installation and broad compatibility.
- Adjustable fan speed controller(FAN MATE 2) enables control of noise and fan speed.
- Does not generate noise or vibration in Silent Mode.

Kompatibilitet
ATI Products:
ATI Radeon X1600 Series
ATI Radeon X1300 Series
ATI Radeon 9*** Series (except 9550/9600)
ATI Radeon X*** Series
ATI Radeon HD4670
ATI Radeon HD4650
ATI Radeon X2600 Series
ATI Radeon X1650 Series
ATI Radeon X1600 Series
ATI Radeon HD 4870
ATI Radeon HD 4850
ATI Radeon HD 4830
ATI Radeon HD 3870, HD 3850
ATI Radeon X1950 Series
ATI Radeon X1900 Series
ATI Radeon X1800 Series

NVIDIA Products:
NVIDIA Geforce 6600 Series (except 6600 AGP Series)
NVIDIA GeforceFX 5600(FX 5700)
NVIDIA GeforceFX 5500
NVIDIA GeforceFX 5200
NVIDIA Geforce4 MX Series
NVIDIA Geforce 6600 Series (except 6600 AGP Series)
NVIDIA GeforceFX 5800 Series
NVIDIA GeforceFX 5700(Ultra) Series
NVIDIA Geforce4 TI 4 Series
NVIDIA Geforce 8600 Series
NVIDIA Geforce 8500 Series
NVIDIA Geforce 7600 Series
NVIDIA Geforce 7300 Series
NVIDIA Geforce 6600 Series (except 6600 AGP Series)
NVIDIA Geforce FX 5950 Series
NVIDIA Geforce FX 5900 Series
NVIDIA Geforce GTS250
NVIDIA Geforce 9800GTX+
NVIDIA Geforce 9800GT
NVIDIA Geforce 9500GT
NVIDIA Geforce 9400GT
NVIDIA Geforce 8800GT, 8800GTS (G92)
NVIDIA Geforce 7950 Series
NVIDIA Geforce 7900 Series
NVIDIA Geforce 7800 Series
NVIDIA Geforce 7600 Series
NVIDIA Geforce 6800 Series
NVIDIA Geforce 8800 Series (G80)

Specifications
Heatsink
- Dimensions: 160(L) X 80(W) X 30(H) mm
- Weight: 380g
- Materials: Dissipation Fins: Pure Copper, Base: Pure Copper, Heatpipe : Pure Copper

Fan
- Dimensions: 80(L) x 80(W) x 15(H) mm
- Bearing Type: 2 Ball-Bearing
- Speed (using FAN MATE 2) - Silent Mode: 1,400rpm ±10% - Normal Mode: 2,500rpm ±10%
- Noise Level (using FAN MATE 2) - Silent Mode: 18dBA ±10% - Normal Mode: 28dBA ±10%

Cautionary Notes
- By installing this product on a VGA (Video Graphics Array) card, a PCI slot adjacent to the PCIe (or AGP) slot will become unusable.
- The product cannot be installed on Matrox VGA cards, NVIDIA PCX 5*** , NVIDIA Geforce 6600 AGP Series, Geforce 7600/7900 AGP Series, and ATI Radeon 9550/9600 Series.
- If the VGA card and/or its components interfere with the installation of this product, then stop the installation, refer to the list of compatible VGA cards at Zalmans website, and install this product with one of the compatible VGA cards.
- NVIDIAs Geforce 8800 Series requires the installation of Zalmans RAM Heatsink ZM-RHS88 before installing VF1000 LED. Except for Geforce 8800GT G92 and Geforce 8800GTS G92.
- The use of a fan positioned on the front side of the case and an exhaust fan positioned on the rear side of the case is recommended for enhancement of product performance.
